Mechanical Department

Facilities available in the Department:

Automobile Engineering Laboratory

  • Cut sectional model of TATA SUMO chassis
  • Chassis Dynamometer for four wheeled vehicles
  • Automatic transmission test rig
  • Cut sectional models for different steering mechanisms
  • Rack and pinion type steering system
  • Re-circulating ball type steering
  • Worm and roller type steering
  • Power steering system
  • Cut sectional models for suspension systems: Front suspension system and rear suspension system
  • Cut sectional models for fuel supply system
NA

Mechanical System Design Laboratory

  • Thermal Cycling Furnace Dip Coating Machine
  • DEFORM software
  • ABAQUS software with XFEM
  • FE-safe software with Thermo Mechanical
  • Fatigue and Turbo Life modules
  • Pin on Disc wear test rig
  • Hydrodynamic bearing test rig
  • Air Jet erosion test rig
NA

Refrigeration and Air Conditioning Laboratory

  • Refrigeration units
  • The following setups are in refrigeration section:
  • Vapor absorption refrigeration system
  • Vapor compression refrigeration system
  • Ice plant system
  • Electrolux Refrigerator
  • Vortex tube refrigerator (R434)
  • Gas charging units
  • Air-conditioning units
  • Air-conditioning system
  • Desert cooler
NA

Steam Engine Laboratory

  • Gas turbine. Nestler boiler.
  • Seprating and Throttling calorimeter.
  • Surface condenser, Thermometers and stopwatch.
  • Compressor test rig.
  • Turbine with condenser, Pump, Dynamometer and Measuring tape.
  • Babcocks and Wilcox boiler model.
  • De laval turbine and Parson\92s turbine model.
  • Locomotive boiler model.
  • Lancashire boiler model.
NA

Internal Combustion Engine Laboratory

  • Computerized single cylinder SI engine coupled with eddy current dynamometer.
  • Four cylinder Four stroke MPFI petrol Engine with Hydraulic Dynamometer.
  • Variable compression ratio petrol Engine test ring with swinging field DC dynamometer.
  • Multi cylinder Kirloskar Diesel Engine with Hydraulic Dynamometer.
  • Four stroke single cylinder Kirloskar Diesel Engine with Electric dynamometer.
  • Single Cylinder 4 stroke Petrol Engine.
  • Two stage Reciprocating Air Compressor.
  • Fuel injection pump test bench
  • Gas calorimeter
  • Two stroke petrol engine model (cut section)
  • Diesel engine cut section Model
  • V8 Ford petrol Engine
  • 2 stroke petrol Engine(Model)
  • 4 stroke petrol Engine model
  • Smoke meter
NA

Computer Aided Design Laboratory

  • CATIA
  • Solidworks
  • Hyperworks (Optistruct)
  • MATLAB
  • 100 Workstations

Heat And Mass Transfer Laboratory

  • Pin fin apparatus.
  • Composite wall apparatus.
  • Metal cylinder with electric heater.
  • Metal bar of brass.
  • Insulating powder and thin walled concentric spheres of copper.
  • Blower to supply air.
  • Gold plate copper tube and plain copper tube.
  • Heat pipe demonstrator.
  • Stefan Boltzman apparatus.
  • Emissivity measurement apparatus.
  • Stainless steel tube and copper tube.
NA

Machine Tools And Advanced Machining Laboratory

  • Electric Discharge Machining System
  • Laser Cutting System
  • High Speed Precision Lathe
  • Tool Grinder
  • Tool Makers Microscope
  • Surface Roughness Tester
  • Digital Semi Microbalance
  • Metallographic Grinding/Polishing Machine
NA

Computational Research Lab

  • Total 12 Nos. of HP Compaq 8200 Elite SFF PC
  • With Intel(R) Core(TM) i7-2600 CPU @ 3.40 GHz and 2.00 GB installed memory (RAM).
NA

Computer Aided Manufacturing Laboratory

  • H. M. T. CNC T-70 AMC No. 94252
  • HMT VMC200T M/C No. 97031
  • HMT VMC 200T M/C No. 97030
  • HMT VMC 200T PC M?C No.97064
  • Lathe 3 Jaw chuck for Orac
  • X-Y Plotter Graphics 8 Pens
  • PC-AT/CPU No.2001 Monitor
  • Magnetic Starter for CNC Lab P. No. 320
  • Servo Controlled A/C 30 KVA for P&D 320
  • CNC Turning Machine P &D. 320 PMT
  • Air Compressor KAC
  • Enterprise 460 CNC Lathe
  • HMT CNC Train Master T 70 PC with Color Monitor 94276
  • 6 Axis Robotic Arm
NA

Materials Characterization Laboratory

  • Dynamic Mechanical Analyzer (DMA)
  • Micro hardness tester- under procurement process
  • Sample mounting machine- under procurement process
  • Grinding Polishing machine- under procurement process
  • Precision electronic weighing balance- under procurement process
  • Ultrasonic cleaner - under procurement process
  • Slow speed sample saw - under procurement process
NA

Instrumentation Laboratory

  • Linear variable differential transformer apparatus
  • Proximity tutor (Capacitive type)
  • Resistance thermal detector (RTD)
  • Luxmeter
  • Elastic transducer
  • Strain gauge (quarter, half and full bridge circuit)
  • Bimetallic Transducer
  • Bourdon pressure gauge
NA

Machine Elements Laboratory

  • 10 Ton servo hydraulic Material Test System of MTS US make
  • 2.5 ton Compact Servo hydraulic Material Test system BISS Make
  • Shimadzu Micro hardness tester
  • Modular Compact Rheometer MCR 52
  • Electric Oven
NA

Metrology Laboratory

  • Floating carriage micrometer
  • Clinometer
  • Tool makers microscope
  • Slip gauges
  • Vernier callipers
  • Micrometer
  • Depth gauge

Product Design and Manufacturing Laboratory

  • 20 Nos PCs for PG thesis students
  • Tezro workstation
  • Optical Measuring Microscope (DST funded)
  • Surface Roughness Tester (DST funded)

Mechatronics and Virtual Instrumentation Laboratory

  • Mechatronics Training Package
  • Linear Conveyor System and Sensor Kit
  • Rotary table with Sensor Kit
  • X-Y table
  • Robot development Kit with Programming in C and Compatible Microcontroller board
NA
Thrust Areas of the Department:
  • Thermal Engineering
  • Turbo Machines
  • Energy Management
  • Heat and Mass Transfer
  • Optimization
  • Functionally Graded materials
  • Computer Aided Geometric Deisgn
  • Industrial Engineering
  • Supply Chain Management
  • Advanced Manufacturing Processes
  • Micro/Nano Manufacturing process
  • IC Engines
  • Robotics and Mechatronics
  • Refrigeration & Air Conditioning
  • Surface Coating Technology
  • Modeling & Simulation
  • Operations Management
  • Composite Materials
  • Biomechanics
